Blindsmart’s PVC Australian Made Shutters offer a classic, timeless look that enhances any décor.

Our PVC shutters come in solid PVC with an aluminium core for stability and carry a 1 year warranty. They are low maintenance and allergy free and allow excellent control of light and airflow. PVC Shutters also offer privacy and are a great insulator assisting with the reduction of energy costs.

Blindsmart’s PVC Shutters are excellent for high moisture areas such as bathrooms and kitchens and are easily cleaned and maintained.

Clear

Plantation Shutters

SKU: N/A Category: Tags: , , , ,

Description

Standard

Hinged.

Shutter Colours

Alpine White, Ivory, Pure White.

Louvre Width

89mm blade (solid PVC with aluminium core).

Louvre Shape

Elliptical only.

Louvre Thickness

11mm.

Clearance

89mm blade – 66mm clearance.

Hinges

White – Off White.
Chrome and Stainless Steel available on request.

Pivot Hinges

White Only.
Please note when ordering multiple panels with pivot hinges requested on the same side, straight stiles will be supplied.

Maximum Panel Height

2600mm.

Mid Rail Height

1 Midrail required for heights greater than 1500mm.
2 midrails required for heights greater than 2100mm.

Hinged Panel

Maximum width: 900mm.
Minimum top and bottom rails for panels up to 700mm wide is 76mm.
Minimum top and bottom rails for panels greater than 700mm is 95mm.

Double Hinged Panel Maximum Width

600m.

Tilt Rod Options

Hidden only.

Stile Profile

Beaded.

Stile Width

50mm

Stile Thickness

27mm.

Rail Thickness

19mm.

Framing Options

Small L Frame, Medium L Frame, Medium L (capped).

Z Frame, 90 degree corner post, 45 degree bay post, Light Block, U Channel.

Deductions

Inside Mount: Factory will deduct 3mm from width and 4mm from height.
Outside Mount: No deductions will be taken.
Make Size: If you do not want deductions taken you must clearly write “Make Size” in the general notes section.

T Posts

Single or multiple T-Posts are available. All measurements are to be supplied from the left hand side to the middle of the T–Post.
If T–Posts are uneven, then you will need to fill out the “Uneven T-Post section of the order form.

Mid Rails

Single or multiple mid rails are available. All measurements are to be supplied from the bottom of your order height to the centre of the mid rail.
Mid rails are only available in one size – approx. 80mm.
Mid rail height can be positioned up or down by a maximum of 20mm by the factory unless ordered as CRITICAL.

Multi Panels

Window orders with two or more panels will come STANDARD with D-Mould.
• You must indicate which panel will require the D-Mould.
• L-DR shows the right hand panel to have D-Mould.
• LD-R shows the left hand panel to have the D-Mould.

Tilt Rod Type

Only hidden tilt rod is available.
• Will be fitted to the rear of the panel on the hinge side unless otherwise specified.
• Shutter panels can have split tilt mechanism, split into 2 or 3 sections without the need for a mid rail.
• Measurement from the bottom of the panel are required.
• Tilt rods will automatically be split at approximately 1000mm.

Striker Plates/Magnet Catches

When ordering frame or light block, magnets will be attached to the rear of the panel and magnet catches supplied.
When ordering direct mount without light block, striker plates will be supplied.

Blindsmart Plantation Shutters come with a 1-year standard warranty.
